EN 10255 - The standard text specifies the requirements for round non-alloy steel pipes suitable for welding and threading and provides various options for surface treatment of pipe ends and coatin...
EN 10255 – The standard text specifies the requirements for round non-alloy steel pipes suitable for welding and threading and provides various options for surface treatment of pipe ends and coatings. The standard covers pipes with specified outer diameters from 10.2mm to 165.1mm (thread sizes 1/8 to 6), divided into two series, medium and heavy, and three specified thicknesses.
EN 10255 Hot Dipped Galvanized Steel Tube Specification
EN 10255 has two types: Heavy type and Medium Type.
O.D: 10.6-166.5mm
W.T: 2.0-5.4mm
L: 5800mm/6000mm
Ends Process: Plain, Threaded, Threaded & Socketed.
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.20 | – | max 1.40 | 0.035 | 0.03 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 320 | 520 | – | 20 | ||
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| – | EN 10255 Grade S195T | – | – | – | – |
