A671 cc60 cl22 steel pipe is an electrofusion welded pipe suitable for high pressure applications at low and normal temperatures. GNEE Group can produce a671 electrofusion welded pipes of different strength levels.
| Pipe Type | ASTM A671 Gr. CC60 EFW Pipe | |
| Executive Standard | API SPEC 5L,GB/T 9711.1,GB/T 9711.2,GB/T 9711.3,SY/T5037 | |
| ASTM A671 | Standard Specification for Electric-Fusion-Welded Steel Pipe for Atmospheric and Lower Temperatures | |
| Class Designation | Class 10, 11, 12, 13, 20, 21, 22, 23, 30, 31, 32, 33, 34, 40, 41, 42, 43, 50, 51, 52, 53, 60, 61, 62, 63, 70, 71, 72, 73. | |
| Size | Outer Diameter | 12-64 inch |
| Wall Thickness | 2-60mm SCH10, SCH20, SCH30, STD, SCH40, SCH60, XS, SCH80, SCH100, SCH120, SCH140, SCH160, XXS |
|
| Length | Single random length/Double random length 5m-14m,5.8m,6m,10m-12m,12m or as the customer’s actual request | |
| Ends | Plain end/Beveled, protected by plastic caps on both ends, cut square, grooved, threaded and coupling, etc | |
| Surface Treatment | Bare, Painting black, varnished, galvanized, anti-corrosion PE PP/EP/FBE coating |
|
| Technical Methods | Hot-rolled | |
| Testing Methods | Eddy current testing, Hydrostatic testing or Ultrasonic examination, NDT, and also with chemical and physical property inspection | |
| Packaging | Small pipes in bundles with strong steel strips, large pieces in loose; Covered with plastic woven bags; Suitable for lifting operation; Loaded in 40ft or 20ft container or in bulk Also according to customer’s requests | |
| Application | Conveying oil, gas and water | |
| MOQ | 30 ton | |
| Production Capacity | 6000 T/M | |
| Delivery Time | 5-8 days | |
| Specification | Steel grade | Chemical composition | Remarks | |||||
| C | Si | Mn | P | S | Ti | |||
| Pipes for pressure service ASTM A671, A672 |
-/A45 | -/0.17 | – | 0.98 | 0.035 | 0.035 | – | A671/ A672 |
| -/A50 | -/0.22 | – | ||||||
| CA55/A55 | 0.28 | – | ||||||
| -/B55 | -/0.20 | 0.13 ~0.45 |
||||||
| CB60/B60 | 0.24 | |||||||
| CB65/B65 | 0.28 | |||||||
| CB70/C70 | 0.31 | 1.30 | ||||||
| -/C55 | -/0.18 | 0.55 ~0.98 |
||||||
| CC60/C60 | 0.21 | |||||||
| CC65/C65 | 0.24 | 0.79 ~1.30 |
||||||
| CC70/C70 | 0.27 | |||||||
| Products | Steel Grade | BASE METAL MECHANICAL COMPOSITION | Welding point tensile strength (N/mm2) | Remarks | |||
| Yield point (N/mm2) | Tensile Stregth (N/mm2) | Test Pieces | Elongation (%) | ||||
| Pipes for pressure service ASTM A671, A672 | -/A45 | -/165 | -/310~450 | – | -/30 | -/310~450 | A671/ A672 |
| -/A50 | -/185 | -/345~485 | -/28 | -/345~485 | |||
| CA55/A55 | 205 | 380~515 | 27 | 380~515 | |||
| -/B55 | -/205 | -/380~515 | -/27 | -/380~515 | |||
| CB60/B60 | 220 | 415~550 | 25 | 415~550 | |||
| CB65/B65 | 240 | 450~585 | 23 | 450~585 | |||
| CB70/B70 | 260 | 485~620 | 21 | 485~620 | |||
| -/C55 | -/205 | -/380~515 | -/27 | -/380~515 | |||
| CC60/C60 | 220 | 415~550 | 25 | 415~550 | |||
| CC65/C65 | 240 | 450~585 | 23 | 450~585 | |||
| CC70/C70 | 260 | 485~620 | 21 | 485~620 | |||
A671 CC60 CL22 EFW Pipe Packaging Type Supplied by GNEE
– Bales (hexagonal)
– Wooden box
– Crate (steel/wood)
– Special crates for U-bends, separate for each radius
– Packing A671 grade cc60, cc65, cc70 carbon steel seamless steel pipe according to customer requirements
GNEE Group has been supplying A671 CC60 CL 22 welded pipe for 16 years, we can provide a large quantity of stock, if you need it you can contact us at any time.
